LeoXZ XF1-Pro New 3K Carbon Edition
This model 100% SimHub compatible
Full SimHub Compatibility, 800x480px IPS Screen, RGB Leds, USB Connection ONLY.
The XF1-Pro-3K features a 275mm diameter polyurethane grip, produced by high-precision molds, has a special coating on its surface, and its delicate texture satisfies various driving needs.
The back cover and paddles are processed using CNC technology and coated with black anodizing to achieve optimal appearance and lasting durability.
The front panel is made of 5mm forged carbon fiber and the paddles are made of 3mm forged carbon fiber.
18 RGB LEDs that can be customized through SimHub.
4.3" IPS screen with a resolution of 800x480 pixels and a 60fps refresh rate, and its dashboard can be customized through SimHub.
16 reliable push buttons, 2 Seven-Way Multi Switches and 3 pressable encoders.
2 metal blue anodized thumb knob included.
It comes with a standard magnetic shifter paddle, and additional clutch and option paddles are available as options.
The clutch paddles can be set to bite point mode, axis mode, and button mode.
All paddles use non-contact Hall sensors for long-lasting durability.
Sturdy and reliable USB-XS9 interface with a locking mechanism.
70mm diameter QR mounting hole.
It can be connected to Leoxz Fanatec QR through the QR cable interface to unlock Fanatec base torque.
It can only be connected through USB for wired connection.
COMPATIBLE HARDWARE
Simucube SC1, SC2
Fanatec DD1, DD2, CSW, CSL DD, DD Pro (Base torque needs to be unlocked with PHUB or Leoxz Fanatec QR, while connecting through USB)
Simagic Ultimate, Alpha, Alpha Mini
Moza R21, R16, R12, R9, R5
Thrustmaster T300, T500, TX, TS-XW, T-GT, T-GT II, and TS-PC (Only support bases that do not require official steering wheel authentication). *Special order only*
For more hardware compatibility information, please click here.
SOFTWARE
PC only with SimHub and SimBridge
SimHub for getting telemetry data
SimBridge is used to receive SimHub data and send to XF1
PACKAGING
Dimensions (LxWxH): 38cm x 29cm x 25cm
Weight: 1.5kg
INCLUDED
XF1 Pro Steering Wheel (Quick release optional)
USB-XS9 Cable
Custom Stickers
M3 Allen Key
Nylon Tweezers
NOTES
Steering wheel can only be used in sim racing
No matter through the USB interface or the quick release power interface, the maximum input voltage can only be 5V
The free version of Simhub only outputs data at 10 frame rate, you need to purchase additional license to have 60 frame rate
The steering wheel must be connected through USB in order to function properly
Download
XF1 Pro Manual
SimBridge
SimHub
